Bimetal thermostat (KSD301)

Switches & protection · Snap disc · 60 °C

Snap-disc bimetal thermostat (KSD301 type) · 250 V 16 A · opens at 60 °C, closes again at 54 °C · clip it to the tank

Try it on the benchThe lab drops it on an empty bench and opens its datasheet card.

Lessons and builds that use it

• Real device: water heater, 220 V AC to hot water (build)
