Logic output

Logic (ideal) · Shows H or L

Logic output: shows H above 2.5 V from ground, L below. Draws no current; it needs a ground symbol on the bench.

Try it on the benchThe lab drops it on an empty bench and opens its datasheet card.

Pins

• in
