12 V PoE router

Networking & PoE · PoE in · PoE out

5-port router · 9–28 V DC via the jack or passive PoE-in on ETH1 · passive PoE-out on ETH5 (input voltage, 1 A max) · 4–6 W

Try it on the benchThe lab drops it on an empty bench and opens its datasheet card.

Pins

• DC jack centre (+)
• DC jack sleeve (−)
• ETH1 · PoE in
• ETH2
• ETH3
• ETH4
• ETH5 · PoE out
