NPN transistor, 300 V (MJE340, TO-126)

USB & power interfaces · MJE340

MJE340 · TO-126 · 300 V · 0.5 A · about 1.25 W in free air (20 W on a heatsink) · β 30–240

NPN transistor, 300 V (MJE340, TO-126) on the simulator's bench

Try it on the benchThe lab drops it on an empty bench and opens its datasheet card.

Pins

E
B
C
