Signal diode (1N4148)
1N4148 · Small-signal switching · 0.3 A · 100 V
Try it on the benchThe lab drops it on an empty bench and opens its datasheet card.
Typical part: 1N4148
Pins
- Anode
- Cathode (band)
Ratings and limits
| Peak inverse voltage | 100 V |
|---|---|
| Forward current | 300 mA (avg) |
| Reverse recovery | 4 ns |
How to use it
Fast small-signal switching: logic, clamping inputs, flyback on small relays.
